100 Ohm Quadrax Cables
Quadrax Data Cables
Products
| Item # | Item Name | Temperature | Impedance | Near End Cross Talk @ 10 MHz per 100 ft. | Near End Cross Talk @ 100 MHz per 100 ft. |
|---|---|---|---|---|---|
| W-3506-26 | 100 Ohm 24 AWG 2 Pair Quadrax Cable | -55 to 200 ºC | 100 ohms | ||
| W-3508-26 | 100 Ohm 24 AWG Aluminized Mylar Shielded Quadrax Cable | -55 to 200 ºC | 100 ohms | 47.0 dB | 32.0 dB |
| W-3516-26 | 100 Ohm 26 AWG 2 Pair Quadrax Data Cable | 100 ohms | |||
| W-3713-379 | 100 Ohm 24 AWG Quadrax Cable | -55 to 150 ºC | 100 ohms | ||
| W-3714-379 | 100 Ohm 26 AWG Quadrax Cable | -55 to 150 ºC | 100 ohms |
Visit the FDH Electronics online store and create an account for special pricing.
